Rincian produk
Tempat asal: Hangzhou, Cina
Nama merek: Zoyo
Sertifikasi: ISO 9241; IEC62341; JEITA CP-3451; ANSI/AAMI ES60601-1-2; IEC 60068
Nomor model: ZY17601
Syarat Pembayaran & Pengiriman
Kuantitas min Order: MOQ fleksibel
Harga: $2~$500 per piece
Kemasan rincian: Disesuaikan
Waktu pengiriman: 3-4 minggu
Syarat-syarat pembayaran: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Menyediakan kemampuan: 5rb-20rb potong per hari
Ukuran (inci): |
1.76 |
Resolusi: |
336*480 |
Pencahayaan (nit): |
450 |
Suhu operasi: |
-20℃～70℃ |
Ukuran (inci): |
1.76 |
Resolusi: |
336*480 |
Pencahayaan (nit): |
450 |
Suhu operasi: |
-20℃～70℃ |
| GENERAL SPECIFICATIONS | ||||
| Item | Specification | Unit | Note | |
| Screen Size | 1.76 | |||
| Resolution | 336*480 | pixels | ||
| Operating Temperature | ‐20 ~ 70 | °C | ||
| Pixel Density | 336 | ppi | ||
| Luminance | 450 | Cd/m2 | - | |
| Module Size | Horizontal (H) | 27.96 | mm | typ |
| Vertical (V) | 36.17 | |||
| Thickness (T) | ‐ | |||
| Active Area | Horizontal | 25.40 | mm | |
| Vertical | 36.29 | |||
| TP | Oncell | |||
| Shape | Bar | |||
| Interface Type | MIPI/SPI | |||
| Color Gamut | DCI-P3 Typ. 100% | |||
| Color depth | 24 | bits | ||
| Contrast Ratio | 1000000:1 | |||
| Power Consumption(mW) | ‐ | mW | ||
| Refresh rate | 60Hz/AOD | |||
| Low Blue Light | 5% | |||
| Kind Tips: More details please contact us for products' specifications | ||||
